3kW Rack Mounted Load Banks

Lub 3kW khib mounted load banks tuaj yeem simulate lub zog siv, cua sov dissipation thiab lwm yam kev hloov pauv huab cua ntawm lub server.

Xa kev nug

Taw qhia

Lub 3kW khib mounted load bank muaj peev xwm simulate lub zog siv, cua sov dissipation thiab lwm yam huab cua hloov pauv ntawm lub server. Los ntawm kev siv cov khib nyiab mounted load bank rau kev sib koom ua ke, kev ua haujlwm zoo ntawm cov khoom siv hluav taws xob thiab kev faib khoom (xws li UPS system), cua txias cua txias system, hluav taws xob tiv thaiv thiab hauv av, kev saib xyuas, ib puag ncig ntawm chav tsev computer, nws ib puag ncig. ntawm txee thiab kho kom zoo nkauj engineering ntawm chav tsev computer yog ua kom ntseeg tau, thiab cov qauv tsim thiab kev ua haujlwm raug txheeb xyuas.

Khib AC dummy load yog dav siv nyob rau hauv cov ntaub ntawv chaw thiab hloov chav. Khib hom AC dummy load kuj siv tau raws li kev thauj khoom hauv lwm qhov kev lag luam.

Tswj qhov system

Cov control ntawm lub txhab nyiaj load yog phau ntawv hauv zostswj.

Cov npe khoom siv

Cov khoom siv	kom muaj nuj nqis.
3kW / AC230V / 50Hz	1
Cov lus qhia ua haujlwm thiab tu	2
Txais daim ntawv pov thawj	1
Kev tshuaj ntsuam xyuas	1
Hluav taws xob schematic	2

Txuj

Kev tsim qauv, tsim khoom thiab kev pabcuam yog nruj me ntsis raws li qhov yuav tsum tau ua ntawm GB/t19001-2008 "Quality Management System", thiab xa mus rau cov qauv hauv qab no. Txoj kev npaj tsim khoom zaum kawg rau lub kaw lus yuav tsum ua raws li kev pom zoo los ntawm ob tog.

National standard
GB/t2820.52009	Ib tug reciprocating internal combustion engine tsav lub alternator. Part 5: Generator Sets
GB/t 13032-2010	Marine diesel generator teeb.
GB/t 1029-2005	Cov kev sim rau peb-theem synchronous motors.
GB 14711-2006	Kev nyab xeeb yuav tsum muaj rau cov tshuab hluav taws xob me me thiab nruab nrab.
Tub rog txuj
GJB 2815-97	General Specification rau Tub Rog Internal Combustion Cav Loads
GJB235a -97	General Specification rau Tub Rog AC Mobile Loads
GJB 235-87	General technical tej yam kev mob rau industrial thiab intermediate zaus mobile loads
GJB 1488-93	General xeem txoj kev rau tub rog internal combustion engine load
Kev lag luam Standard
JB/t10303-2001	Technical tej yam kev mob ntawm lub hwj chim zaus diesel generator teev

Qhuav Taw Qhia

Nco tseg: tag nrho cov tsis yog rau kev siv nkaus xwb thiab tuaj yeem hloov kho
Khoom npe	3kW khib mounted load banks
Rated voltage	AC 230 V
Max load zog	1 kW
Thauj cov kauj ruam	1 kW, 1 kW, 1 kW
Load precision (ib lub iav)	± 2 feem pua
Kev sib txuas hom	Peb lub tswv yim, ywj siab tswj fais fab input
Tswj fais fab	AC220V / 50Hz
Rwb thaiv tsev chav kawm	F
Hom kev ua haujlwm	Kev ua haujlwm tsis tu ncua
Txias hom	Forced cua txias, cua pem hauv ntej, cua nram qab
Tswj hom	Load switching ntawm phau ntawv me me Circuit Court breaker
Kev tiv thaiv muaj nuj nqi	Kub tswb tswb (70 degree) kub tsis siv neeg unloading (85 degree)
Xim	Customized
Ambient kub	-20 degree rau 50 degree
Cov av noo	Txog li 100 feem pua
Qhov siab	Txog li 2500m
Atmospheric siab	86 rau 106kPa

Qhuav Taw Qhia

Nco tseg: tag nrho cov tsis yog rau kev siv nkaus xwb thiab tuaj yeem hloov kho
Lub zog (kW)	Qhov voltage (V)	Ntau zaus (Hz)	Qhov siab	Loading kauj ruam	Kev xaiv muaj nuj nqi
3	220/240	50/60	3U	0.5kW lossis 1kW	Ntxuam ceev tswj, dual fais fab hloov
3.5	220/240	50/60	3U
4	220/240	50/60	4U
4.5	220/240	50/60	4U
5	220/240	50/60	4U
6	220/240	50/60	6U
7	220/240	50/60	6U
8	220/240	50/60	8U
9	220/240	50/60	8U
10	220/240	50/60	8U
12	220/240	50/60	12U
